Chapter 4 Wiring
4-5
4.1.2 How to separate front cover when wiring
(90~375 kW 400V, 30-75kW 200V)
Releasing the right/left fixed bolt on the lower front cover and get down the lower front
cover and then open it. Now, you can wire power part (R/S/T, P/N, U/V/W) and signal
cable (terminal block, encoder option, communication option, PLC option etc.).
