LSIS SV-iS7 series User Manual

Chapter 4 Wiring
4-14
4.1.8 Specifications of power terminal block and Exterior fuse
Inverter applied
Terminal
Screw
size
Screw torque
1)
(Kgf·cm)
Cable
2)
Exterior fuse
mm
²
AWG
R,S,T U,V,W R,S,T U,V,W Current Voltage
2
0
0
V
0.75 kW M4 7.1~12 2.5 2.5 14 14 10A
500V
1.5 kW M4 7.1~12 2.5 2.5 14 14 15A
2.2 kW M4 7.1~12 2.5 2.5 14 14 20A
3.7 kW M4 7.1~12 4 4 12 12 32A
5.5 kW M4 7.1~12 6 6 10 10 50A
7.5 kW M4 7.1~12 10 10 8 8 63A
11 kW M6 30.6~38.2 16 16 6 6 80A
15 kW M6 30.6~38.2 25 22 4 4 100A
18.5 kW M8 61.2~91.8 35 30 2 2 125A
22 kW M8 61.2~91.8 35 30 2 2 160A
30 kW M8 61.2 ~ 91.8 70 70 1/0 1/0 200A
37 kW M8 61.2 ~ 91.8 95 95 2/0 2/0 250A
45 kW M8 61.2 ~ 91.8 95 95 2/0 2/0 350A
55 kW M10 89.7 ~ 122.0 120 120 3/0 3/0 400A
75 kW M10 89.7 ~ 122.0 150 150 4/0 4/0 450A
4
0
0
V
0.75~1.5kW M4 7.1~12 2.5 2.5 14 14 10A
500V
2.2 kW M4 7.1~12 2.5 2.5 14 14 15A
3.7 kW M4 7.1~12 2.5 2.5 14 14 20A
5.5 kW M5 24.5~31.8 4 2.5 12 14 32A
7.5 kW M5 24.5~31.8 4 4 12 12 35A
11 kW M5 24.5~31.8 6 6 10 10 50A
15 kW M5 24.5~31.8 16 10 6 8 63A
18.5 kW M6 30.6~38.2 16 10 6 8 70A
22 kW M6 30.6~38.2 25 16 4 6 100A
30~37 kW M8 61.2~91.8 25 25 4 4 125A
45 kW M8 61.2~91.8 70 70 1/0 1/0 160A
55 kW M8 61.2~91.8 70 70 1/0 1/0 200A
75 kW M8 61.2~91.8 70 70 1/0 1/0 250A
90 kW M12 182.4~215.0 100 100 4/0 4/0 350A
110 kW M12 182.4~215.0 100 100 4/0 4/0 400A
132 kW M12 182.4~215.0 150 150 300 300 450A
160 kW M12 182.4~215.0 200 200 400 400 450A
185 kW M12 182.4~215.0 200 200 400 400 620A
