Chapter 3 Installation
3-4
3.1.2 Exterior and Dimension (UL Enclosed Type 1, IP21 Type)
1) SV0008-0037iS7 (200V/400V)
mm ( inches )
Inverter
capacity
W1 W2 H1 H2 H3 D1 A B
SV0008~0037
iS7 - 2/4
150(5.90) 127(5.00) 284(11.18) 257(10.11) 18(0.70) 200(7.87) 5(0.19) 5(0.19)
