Chapter 5 How to Use Keypad
5-12
5.1.6 Parameter setting
1) Parameter setting in modes and groups
This gives an example of changing frequency in the Drive Group of Parameter
Mode. You can do so too in other modes or groups.
- This is the initial display of Parameter Mode.
- Press Down key.
- You have shifted to 01 frequency setting
code.
- Press PROG.
- The cursor flashes so that you can enter
frequency.
- If you want to set the frequency at 10Hz,
move the cursor to the desired place using
Left/Right keys.
- Enter 10Hz using Up key and press PROG.
- The desired frequency has been changed to
10Hz.
PAR
G
DRV N STP 0.00Hz
00 Jump Code
9 CODE
01 Cmd Frequency
0.00 Hz
02 Cmd Torque
0.0 %
PAR
G
DRV N STP 0.00Hz
00 Jump Code
9 CODE
01 Cmd Frequency
0.00 Hz
02 Cmd Torque
0.0 %
PAR
G
DRV N STP 0.00Hz
00 Jump Code
9 CODE
01 Cmd Frequency
10.00 Hz
02 Cmd Torque
0.0 %
PAR
G
DRV N STP 0.00Hz
01 Cmd Frequency
10.00 Hz
0.50 ~ 60.00 Hz
D:0.00 C:0.00
PAR
G
DRV N STP 0.00Hz
01 Cmd Frequency
0.00 Hz
0.50 ~ 60.00 Hz
D:0.00 C:0.00
