Chapter 3 Installation
3-23
Inverter
Capacity
W
[mm]
H
[mm]
D
[mm]
EMC&DCL
Weight
[Kg]
Only EMC
Product
weight[Kg]
Only DCL
Product
weight[Kg]
Non EMC
and DCL
Product
weight[Kg]
SV1100iS7-4 510 783.5 422.6 - - 101 -
SV1320iS7-4 510 861 422.6 - - 114 -
SV1600iS7-4 510 861 422.6 - - 114 -
SV1850iS7-4 690 1078 450 - - -200 -
SV2200iS7-4 690 1078 450 - - -200 -
SV2800iS7-4 771 1138 440 - - - 252-
SV3150iS7-4 922 1302.5 495 - - - -352
SV3750iS7-4 922 1302.5 495 - - - -352
Note
Weight[Kg] above indicates the total weight including EMC FILTER and DCL. (excluding
box packing) 30 through75 kW (200V) products don’t have an option type. 30 through
160kW(400V) products have only DCL option type. 280 through 375kW (400V) products
have not EMC and DCL option.
