Chapter 2 SpecificationsG
G
2-4
2) Operation
Operating Method
Selectable among keypad/ terminal block/
communication operation
Frequency Setting
Analog : 0 ~ 10[V], -10 ~ 10[V], 0 ~ 20[mA]
Digital : keypad
Operating Function
PID control, up-down operation, 3-wire operation, DC break,
Frequency limit, Frequency jump, Second function, Slip
compensation, Reverse rotation prevention, Auto restarting,
Inverter By-pass, Auto tunning Flying Start, Energy buffering,
Power breaking, Flux breaking, Leakage current reduction,
MMC, Easy Start
Input
Multi-function
Terminal
(8 points)
P1 ~ P8
1)
NPN (Sink) / PNP (Source) selectable
Function: forward operation, reverse operation, reset, external
trip, emergency stop, jog operation, sequential frequency-
high/medium/low, multi - level acceleration and deceleration –
high/medium/low, D.C. control during stop, selection of a second
motor, frequency increase, frequency decrease, 3-wire
operation, change to general operation during PID operation,
Main inverter body operation during option operation, analog
command frequency fixation, acceleration and deceleration stop
selectable
Output
Multi-function
Open Collector
Terminal
Failure output and inverter
operation output
Below DC 26V, 100mA
Multi-function
Relay Terminal
Below (N.O., N.C.) AC250V 1A,
Below DC 30V 1A
Analog Output
0 ~ 10 Vdc (below 20mA) : selectable from frequency, current,
voltage, direct current voltage
1) The Functions for Multi-function terminal available according to IN-65~72 parameter
setting of IN Group.
