Chapter 2 General Specification
2-1
Chapter 2 General Specification
2.1 General Specification
General specification is as follows.
No. Item Specifications
Related
standards
1
Operating
temperature
0 ~ 55 °C
2
Storage
temperature
−25 ~ +70 °C
3
Operating
humidity
5 ~ 95%RH, no condensation
4 Storage humidity 5 ~ 95%RH, no condensation
5
Vibration
immunity
If intermittent vibration exists -
Frequency Acceleration Amplitude Times
IEC61131-2
10 ≤ f < 57Hz − 0.075mm
10 times to
X, Y and Z
directions,
each
57 ≤ f ≤ 150Hz 9.8m/s
2
−
If continuous vibration exists
Frequency Acceleration Amplitude
10 ≤ f < 57Hz − 0.035mm
57 ≤ f ≤ 150Hz 4.9m/s
2
−
6 Shocks
• Max. impact acceleration : 147 m/s
2
• Time allowed : 11ms
• Pulse waveform : half sine wave (3 times to X, Y and Z directions, each)
IEC61131-2
7 Noise immunity
Rectangular
impulse noise
AC: ±1,500 V
DC: ± 900 V
Test specifications
of LSIS
Electrostatic
discharge
Voltage : 4kV (contact discharge)
IEC61131-2
IEC61000-4-2
Radiating
electronic field
noise
80 ~ 1,000 ㎒, 10V/m
IEC61131-2,
IEC61000-4-3
Fast transient /
Burst noise
Type
Power
module
Digital/Analogue Input/Output,
Communication interface
IEC61131-2
IEC61000-4-4
Voltage 2kV 1kV
8 Environment Free of corrosive gas and dust
9 Altitude Lower than 2,000m
10 Pollution degree 2 and lower
11 Cooling method Natural air cooling type
Note
1) IEC(International Electro technical Commission)
: International private group facilitating international cooperation of electric/electronic standardization, issuing
international standards and operating the compliance evaluation systems.
2) Pollution degree
: As an index representing the pollution degree
of an environment to determine the insulation of a device,
pollution degree 2 generally means the status generating non-conductive contamination. H
owever, it also
contains the status generating temporarily conduction due to condensation.
