Chapter 1 General
XGB series transistor output type contains 2 positioning axes. This manual describes the specifications and
usage of positioning.
1.1.1 Purpose of position function
The purpose of position function is to exactly move an object from the current position to a designated
position and this function executes highly precise position control by sending a position pulse string
signal to types of servo drive or stepping motor control drive. For applications, it may be widely used;
for instance, machine tools, semiconductor assembling machine, grinder, small machine center, lifter
and etc.
< XGB positioning function general >
< Positioning system inner block diagram >
