Chapter 3 Before positioning
3- 38
•
In the case, S/W upper/lower limit detection is available as long as origin is set and the position
mark during constant speed operation is “Mark”
(11) Use of Upper/Lower Limits
• To use upper/lower limits during operation, it should be set as “Use”.
• Upper/Lower limit input contact point is fixed as the table below and it can be used as normally
closed contact point (B contact point).
•
If ‘No use’ is set, it does not detect upper/lower limits and is available with general input contact.
Signal
name
Input contact point number
Operation content Reference
Standard High end
External
low limit
signal
(LimitL)
X axis P0000 P0008
Detects the X axis external lower limit
at the rising edge of input contact point
Acts as
normally
closed
contact point
(B contact
point)
Y axis P0002 P000A
Detects the Y axis external lower limit
at the rising edge of input contact point.
External
upper limit
signal
(LimitH)
X axis P0001 P0009
Detects the X axis external upper limit
at the rising edge of input contact point.
Y axis P0003 P0008
Detects the Y axis external upper limit
at the rising edge of input contact point.
3.2.4 Origin/Manual Parameter Setting for Positioning
Here describes setting range, method of origin/manual parameter for positioning, and special K area
for positioning corresponding to each item. They are summarized as the table below.
Item Setting range
Initial
value
Dedicated
K area
Data size
X axis
XBM/XBC
XEC
Y axis
XBM/XBC
XEC
Home Return
method
0 : origin detection after DOG off
1 : origin detection after deceleration
when DOG is On
2 : origin detection by DOG
0
K4780-81
%KX7648-49
K5180-81
%KX8288-89
2 Bit
Home Return
direction
0 : forward, 1 : backward 1
K4782
%KX7650
K5182
%KX8290
Bit
Origin address -2,147,483,648 2,147,483,647[pulse]∼ 0
K469
%KD234
K509
%KD254
Double word
Home Return high
speed
1 100,000[pulse/∼ s]
5,000
K471
%KD235
K511
%KD255
Double word
Home Return low
speed
1 100,000[pulse/∼ s] 500
K473
%KD236
K513
%KD256
Double word
Home Return ACC
time
0 ~ 10,000[unit: ms] 1,000
K475
%KW475
K515
%KW515
Word
Home Return DEC
time
0 ~ 10,000[unit: ms] 1,000
K476
%KW476
K516
%KW516
Word
Dwell time 0 ~ 50,000[unit: ms] 0
K477
%KW477
K517
%KW517
Word
Jog high speed 1 100,000[pulse/∼ s]
5,000
K479
%KD239
K519
%KD259
Double word
Jog low speed 1 100,000[pulse/∼ s] 1,000
K481
%KD240
K521
%KD260
Double word
Jog ACC time 0 ~ 10,000[unit: ms] 1,000
K483
%KW483
K523
%KW523
Word
Jog DEC time 0 ~ 10,000[unit :ms] 1,000
K484
%KW484
K524
%KW524
Word
Inching speed 1 65,535[pulse/∼ s] 100
K485
%KW485
K525
%KW525
Word
