Chapter 2 General Specification
2-2
2.2 Power Specification
Power specification of XGB series main unit is as follows.
2.2.1 Standard type(XBM-DN□□S) power specification
Item Specification
Input
Rated input voltage
DC24V
Input voltage range DC20.4~28.8V(-15%, +20%)
Inrush current
70A
Peak
or below
Input current
Max. 1A (Typ. 550
㎃
)
Efficiency
60% or above
Allowed temporary
cutoff
1 ㎳ or below
Output
Output voltage
DC5V (±2%)
Output current
Max 1.5 A
Voltage status display
When power is normal, PWR LED On
Cable specification
0.75 ~ 2 ㎟
2.2.2 Compact standard type (XB(E)C-DR/DN/DP□□S(U)) power specification
Item
Specification
XB(E)C-
DR(N)(P)20S(U)
/DR(N)(P)30S(U)
XB(E)C-
DR/DN/DP40SU
XB(E)C-
DR/DN/DP60SU
Input
Rated input voltage AC 100 ~ 240 V
Input voltage range
AC85~264V(-15%, +10%)
Inrush current 50APeak or below
Input current
0.5A or below (220V), 1A or below (110V)
Efficiency
65% or above
Allowed temporary
cutoff
10 ㎳ or below
Output
Output
voltage
DC5V
1.5A
2A
2.5A
DC24V
0.3A
0.3A
0.5A
Output
voltage
ripple
DC5V
DC 4.9 ~ 5.1V (±2%)
DC 4.9 ~ 5.15V (-2%, +3%)
DC24V
DC21.4~26.4 V(±2%)
Voltage status display When power is normal, PWR LED On
Cable specification 0.75 ~ 2 mm
2
* For protection of power supply, use power supplier which has maximum 4A fuse.
