NTP-021
: System Turnup 363-206-305
Page 2 of 12 Issue 3, June 2000
DDM-2000 F
IBER
R
EACH
W
IDEBAND
S
HELF
DO ITEMS BELOW IN ORDER LISTED. . . . .FOR DETAILS, GO TO
NOTE:
This procedure is used to establish a single-homed
DDM-2000 FiberReach OC-3/ OC-12 ring connection to an
FT-2000 ring (See Figure 1). Other configurations may have
to be established to obtain your final configuration. See
NTP-022
for dual-homed configurations from the FT-2000
low speed interface (
LS INTFC
) ports.
Determine the network configuration (for example, see Figure 1).
2. Verify that the host FT-2000 OC-48 shelf is equipped with TARP
Release 8.1 or later ring software. If not equipped with TARP
Release 8.1 or later software, upgrade the FT-2000 OC-48 host
shelf with proper software. Verify that the DDM-2000 FiberReach
shelves are equipped with TARP Release 3 (OC-3) or Release 4
(OC-3 or OC-12) ring software.
3. Determine the optical loss of each optical span from office records
or by making the required measurements.
4. At FT-2000, verify/provision the FT-2000 low speed OC-3/OC-12
slots Protection Mode (from OC-3/OC-12) Parameter to ”
0X1“
(See CONFIGURATION-Set-OC3 or
CONFIGURATION-Set-OC12 command in 365-575-103,
FT-2000 OC-48 Lightwave System, Release 8.1 Through 9.1,
User/Service Manual)
.
5. At FT-2000 shelf, verify/assign DCC channels to FT-2000 low
speed OC-3/OC-12 slots. (See
CONFIGURATION-Enter-Assignment-DCC command in
365-575-103,
FT-2000 OC-48 Lightwave System, Release 8.1
Through 9.1, User/Service Manual)
.
To Next Page
