363-206-305
Technical Specifications
Issue 3 June 2000
10-57
Table 10-25. Power Dissipation - Wideband Shelf
Configuration
Power Dissipation
with 2
26G2-U
with 2
28-Type
with 29G-U
or 29H-U
DDM-2000 FiberReach WBS with 8 BBF3 circuit packs
(16 DS1s, 1x1 protected)
41 Watts 44 Watts 48 Watts
DDM-2000 FiberReach WBS with 8 BBF3 circuit packs
(28 DS1s, 1x7 protected)
38 Watts 41 Watts 45 Watts
DDM-2000 FiberReach WBS with 8 BBF6 (T1EXT)
circuit packs (8 T1EXT, 1x1 protected)
66 Watts 69 Watts 73 Watts
DDM-2000 FiberReach WBS with 8 BBF6 (T1EXT)
circuit packs (14 T1EXT, 1x7 protected)
65 Watts 68 Watts 72 Watts
DDM-2000 FiberReach WBS with 3* BBF8 circuit packs
(6 HDSL, unprotected)
— 46 Watts 50 Watts
DDM-2000 FiberReach WBS with 8 BBF3 circuit packs
(16 DS1s, 1x1 protected) and 2 BBG4B circuit packs
— 50 Watts 54 Watts
DDM-2000 FiberReach WBS with 8 BBF3 circuit packs
(28 DS1s, 1x7 protected) and 2 BBG4B circuit packs
— 47 Watts 51 Watts
DDM-2000 FiberReach WBS with 8 BBF6 (T1EXT)
circuit packs (8 T1EXT, 1x1 protected) and 2 BBG4B
circuit packs
— 75 Watts 79 Watts
DDM-2000 FiberReach WBS with 8 BBF6 (T1EXT)
circuit packs (14 T1EXT, 1x7 protected) and 2 BBG4B
circuit packs
— 74 Watts 78 Watts
DDM-2000 FiberReach WBS with 3* BBF8 circuit packs
(6 HDSL, unprotected) and 2 BBG4B circuit packs
— 52 Watts 56 Watts
DDM-2000 FiberReach WBS with 8 BBF3 circuit packs
(16 DS1s, 1x1 protected) and 2 BBG19 circuit packs
— 50 Watts 54 Watts
DDM-2000 FiberReach WBS with 8 BBF3 circuit packs
(28 DS1s, 1x7 protected) and 2 BBG19 circuit packs
— 47 Watts 51 Watts
DDM-2000 FiberReach WBS with 8 BBF6 circuit packs
(16 DS1s, 1x1 protected) and 2 BBG19 circuit packs
— 75 Watts 79 Watts
* Limited to 3 due to power limitations from a single 28-type.
!
CAUTION:
This information is for a typical application only. Consult 801-525-168, DDM-2000 Floor Plan
Data Sheets, and T82046-30, Power Systems DC Distribution Circuit for Digital Transmission
System, for proper engineering of battery plant and feeders.
Table continued on next page
