363-206-305
Shelf Descriptions and Configurations
3-40
Issue 3 June 2000
Figure 3-34. STAC System, FRC 2000 Module Wall Mount Option with Separate Pedestal
Battery Module
ELECTRONICS MODULE
(WALL MOUNTED)
(FLOOR MOUNTED)
WALL/FLOOR MOUNT OPTION
PEDESTAL BATTERY
MODULE
