Lucent Technologies FiberReach DDM-2000 - Universal Optical Connector

363-206-305
Circuit Pack Descriptions
Issue 3 June 2000
7-63
Figure 7-25. Universal Optical Connector
A3080
Buildout
(White)
FC - Type
A2060 / A3060
Buildout (Blue)
SC - Type
ST
ST
LUCENT
A2070 / A3070
Buildout (White)
-Type
Faceplate-mounted block
that universally accepts
, SC, or FC buildout
R
