363-206-305
Transmission and Synchronization
5-10
Issue 3 June 2000
Figure 5-4. External Timing in a Ring Configuration
TGS
OLIU
DDM-2000
FiberReach
OLIU
DDM-2000
FiberReach
OLIU
DDM-2000
FiberReach
Line TimedLine Timed
Line Timed
External Clock
DDM-2000 OC-3
or
SLC®-2000 ARM Shelf
tpa 843625/01
