Lucent Technologies FiberReach DDM-2000 - Universal Buildout Attenuators

363-206-305
Technical Specifications
10-42
Issue 3 June 2000
Universal Optical Connectors
10
The DDM-2000 FiberReach Multiplexers provide Lucent's universal optical
connector on the OLIUs. This connector is a 2-part connector consisting of a
faceplate-mounted block and an optical buildout. The faceplate block optionally
supports an ST, SC, or FC-type optical buildout.
A 0 dB ST-type connector is shipped as standard with each OLIU except for
22G-Us. Optional SC or FC 0 dB, or attenuated buildouts can be ordered
separately as listed in Table 10-21.
NOTE:
Two 0 dB SC-type removable connectors are installed on 22D-U, 22G4-U,
29G-U, and 29H-U OLIUs. Two 0 dB ST connectors are shipped loose with
these packs.
Table 10-21. Universal Buildout Attenuators
Description Connection Loss (dB) Comcode
A3060 SC 0 dB buildout SM-SM 0 106708951
A3060B1 SC 5 dB buildout SM-SM 5 107406142
A3060D1 SC 10 dB buildout SM-SM 10 107406159
A3060F1 SC 15 dB buildout SM-SM 15 107406167
ASCM5 SC 5dB buildout SM-MM 5 108440579
ASCM10 SC 10dB buildout SM-MM 10 108440595
ASCM15 SC 15dB buildout SM-MM 15 108440611
A3070
ST

0 dB buildout SM-SM 0 106795354
A3070B1
ST
5 dB buildout SM-SM 5 107406183
A3070D1
ST
10 dB buildout SM-SM 10 107406191
A3070F1
ST
15 dB buildout SM-SM 15 107406209
ASTM5 SC 5dB buildout SM-MM 5 108052960
ASTM10 SC 10dB buildout SM-MM 10 108052994
ASTM15 SC 15dB buildout SM-MM 15 108053018
A3080 FC 0 dB buildout SM-SM 0 106795404
A3080B1 FC 5 dB buildout SM-SM 5 107406225
A3080D1 FC 10 dB buildout SM-SM 10 107406233
A3080F1 FC 15 dB buildout SM-SM 15 107406241
AFCM5 FC 5dB buildout SM-MM 5 108107285
AFCM10 FC 10dB buildout SM-MM 10 108107301
AFCM15 FC 15dB buildout SM-MM 15 108107327
