Lucent Technologies FiberReach DDM-2000 User Manual

363-206-305
Technical Specifications
Issue 3 June 2000
10-41
Example:
■
For the 22F, if circuit pack population is between 76 and 231, number of
recommended spares is 2.
21G3-U (1768) 141 433 827 1280 1794 2318 08/24/1999
22D-U (1959)
*
127 391 746 1155 1619 2092 08/24/1999
22F (3317) 75 231 441 682 956 1236
22F2-U (2033) 123 377 719 1113 1560 2016 09/02/1998
22G-U (2880)
*
87 266 507 786 1101 1423
22G2-U (2197) 114 349 665 1030 1444 1866 09/02/1998
22G3-U (4078) 61 188 358 555 778 1005 08/24/1999
22G4-U (1426)
*
175 537 1025 1587 2225 2874 08/24/1999
23G (10029) 25 76 146 226 316 409
23G-U (9023) 28 85 162 251 352 454
23H (12836) 19 60 114 176 247 319
23H-U (11552) 22 66 127 196 275 355
23R (8364) 30 92 175 271 379 490
23R-U (9807) 25 78 149 231 323 418
23S (11470) 22 67 127 197 277 357
24G-U (2080)
*
120 368 703 1088 1525 1971 08/24/1999
24H-U (2388) 104 321 612 948 1328 1716 08/24/1999
26G-U (2468) 101 311 592 917 1285 1661
26G2-U (2525) 99 303 579 896 1256 1623 08/24/1999
27G-U (3176) 79 241 460 713 999 1291
27G2-U (2823) 88 271 518 802 1124 1452 08/24/1999
28G-U (3860) 65 199 379 586 822 1062 09/02/1998
28G2-U
†
29G-U (3264)
*
76 235 448 693 972 1256 12/22/1999
29H-U (3049)
*
82 251 479 742 1040 1344 12/28/1999
* These OLIU circuit packs are equipped with a factory installed, removable SC-type buildout lightguide
connector. Two 0 dB ST connectors are shipped loose with the circuit pack except for 22G-Us.
† Information not available at time of document release.
Plug-In Code (FIT)
Number of Spares Revised Date
NS=1 NS=2 NS=3 NS=4 NS=5 NS=6
NRT
0.14 0.43 0.82 1.27 1.78 2.3
