Lucent Technologies FiberReach DDM-2000 User Manual

363-206-305
Shelf Descriptions and Configurations
3-14
Issue 3 June 2000
Wideband Shelf Plug-Ins
3
Table 3-1 lists the DDM-2000 FiberReach Multiplexer wideband shelf plug-ins.
NOTE:
28-type or 29-type is required. A maximum of 3 HDSL cards per shelf is
allowed and cannot be mixed with other low-speed packs.
!
CAUTION:
In addition to primary lightning protection, an external Lighting and Surge
Secondary Protection Assembly (ED-8C783-30 or equivalent) is required for
circuit packs used in outside plant applications.
Table 3-1. DDM-2000 FiberReach Wideband Shelf Plug-Ins
Product Code Functional Name Functional
Designation
BBF1B DS1 Low-Speed Interface DS1
BBF3/BBF3B DS1 Performance Monitoring DS1PM
BBF6 T1 Extensions T1EXT
BBF8 (See Note) HDSL Interface HDSL
BBG4 DS3 low-speed interface DS3
BBG4B DS3 low-speed interface DS3
BBG8/BBG8B System Controller SYSCTL
BBG19 DS3 Interface DS3
22D-U OC-3 IS-3 OLIU with TSI OLIU
22F/22F-U/22F2-U OC-3 OLIU with TSI OLIU
22G-U/22G2-U/22G3-U/22G4-U OC-3 OLIU with TSI OLIU
26G2-U OLIU OC-1 OLIU with TSI OLIU
28G-U
*
* Requires Interconnect Cable Assembly (847721271)
OC-3 OLIU with TSI OLIU
28G2-U* OC-3 OLIU with TSI OLIU
29G-U* OC-12 OLIU with TSI OLIU
29H-U* OC-12 OLIU with TSI OLIU
177A Retainer
ECC2
†
† The user panel is part of the wideband shelf assembly but may also be ordered separately.
User Panel USPNL
