363-206-305
Operations Interfaces
6-12
Issue 3 June 2000
Pushbutton Combinations
6
The three pushbuttons described previously are used in combinations to perform
seven functions. Figure 6-1 lists the functions. These functions are used as part of
the procedures described in the TOP section of this manual.
Table 6-1. DDM-2000 FiberReach Pushbutton Combinations
Equipment Indicators
6
FAULT Indicators
6
Red FAULT indicators are provided on all circuit packs. The circuit pack FAULT
indicator is illuminated whenever a failure has been isolated to that pack.
Common failures (for example, power, synchronization, control, etc.) do not cause
the FAULT indicators on all circuit packs affected by the failure to be illuminated;
only the FAULT indicator on the failed pack is illuminated.
FAULT indicators on high- and low-speed transmission interface packs are flashed
when a failure of the incoming signal is detected. For example, loss of signal, loss
of frame, loss of pointer, or crossing of the signal fail or signal degrade threshold.
The FAULT LED on the SYSCTL flashes when a failure of the DCC from a far-end
shelf is detected.
Function
Pushbutton
ACO/TST UPD/INIT FE SEL
1. Update Press
2. SYSCTL Initialization
∗
Press
3. Remove SYSCTL †Press Press
4. Software version Hold
5. LED test Hold
6. Alarm cutoff Press
7. Software download †Hold
∗
∗
Used after a SYSCTL is replaced. Press pushbutton during the 10-second
interval that the CR LED on the user panel is flashing.
â€
See TOP section of this manual (Volume II) for detailed procedures.
