363-206-305
Applications
Issue 3 June 2000
2-47
Figure 2-36. STS-3c Dual 0X1 Application (Release 3.1 or Later)
OC-3 Drop
main-1 main-2
28-type OLIU 28-type OLIU
ATM Broadband Connection
cct = twoway (2waypr)
fn-1 fn-2
tpa 852445/01
22-type OLIU 22-type OLIU
FiberReach
Shelf
