Lucent Technologies FiberReach DDM-2000 - Transmission Specifications - VF Channel Units with Adjustable Settings

363-206-305
Technical Specifications
10-72
Issue 3 June 2000
Table 10-32. Transmission Specifications — VF Channel Units with Adjustable
Settings
Parameter
2-Wire E
SPOTS
®
CUs(AUA42, AUA43)
4-Wire CUs
(AUA41, AUA44, AUA54)
Loop Resistance (beyond
HDT, excluding telset)
CSA loops 0-2800 ohms (loop start,
ground-start) 0-5000 ohms
(DX)
Gain Range (Granularity)
Metallic Interface to digital
line
−
1.0 dB to 6.75 dB
(in 0.25-dB steps)
Range depends on function
code
Digital line to metallic
interface
−
8.0 dB to 1.5 dB
(in 0.25-dB steps)
Granularity
=
0.1 dB
Gain Tracking
Input
−
37 to
+
3 dBm
±
0.25 dB
±
0.25 dB
Input
−
50 to
−
37 dBm
±
0.50 dB
±
0.50 dB
Equalization (Slope type) Equalized CSA
cable roll-off at 0.4 kHz
varies from 0.0 dB to 1.1
dB; at 2.8 kHz, roll-off
varies from 0.3 dB to 1.75
dB
Post-equalization of cable
less than 15 dB (H88) or 18
kft (NL) is comparable to D4
4FXS CU (J98726SB). Pre-
equalization and post-
equalization available by
emulating 150-ohm
mismatch.
Structural Impedance
600 ohms
+
2.16
µ
F or 900
ohms
+
2.16
µ
F
600 ohms or 1200 ohms
ERL/SRL (2-wire return loss
with 4-wire path broken)
28/20 dB
RL (any Hz) / RL (1 kHz) 23/28 dB
Balance Capability, CSA
loops
ERL better than 12 dB at
digital line interface of
channel unit facing loop
—
Longitudinal Balance
(IEEE method)
AUA42 AUA43
200 Hz 63 dB 58 dB 67 dB
500 Hz 63 dB 58 dB 67 dB
1,000 Hz 63 dB 58 dB 67 dB
Continued on next page
