363-206-305
Technical Specifications
Issue 3 June 2000
10-71
Longitudinal Balance at the HDT
(Minimum)¶
200 Hz, 500 Hz, 1,000 Hz:
≥
58 dB
3,000 Hz:
≥
53 dB
Equal-Level Cross talk Better than
−
65 dB (200 Hz to 3,400 Hz)
* Measured as insertion loss between 900-ohm terminations.
†Measured with respect to 900 ohms and 2.16
µ
F with the opposite end terminated
in 900 ohms in series with 2.16
µ
F.
‡ Measured with 900-ohm terminations on both ends.
¶ Measured with IEEE method 455-1976.
Table 10-31. Transmission Specifications — AUA45 Dual Ringing Repeater
Channel Unit—
Continued
Parameter Value (Measured at 25
°
C
)
