Lucent Technologies FiberReach DDM-2000 User Manual

363-206-305
Commands and Reports
11-4
Issue 3 June 2000
Table 11-1. DDM-2000 FiberReach Address Table
Object Entity Address Example
Entire system all all
Main slot main-{1,2,all} main-all
Function unit slot
(R3.1 and later)
fn-{1,2,all} fn-all
Function unit pair
(R3.1 and later)
fn fn
Slots Low speed slot ls-all
ls-{a,b,c,d}-{1-2,all}
ls-all
ls-b-2
Sys. control slot sysctl sysctl
Aux. control slot auxctl auxctl
Low speed protection
assembly
lsprot lsprot
OC-1 line (using 26-type
OLIUs in Main)
all
main-{1,2,all}
all
main-1
Lines
OC-3 Line (using 28-type
OLIUs in Main)
all
main-{1,2,all}
all
main-1
OC-12 Line (using 29-type
OLIUs in Main, Rel. 4.0 and
later)
all
main-{1,2,all}
all
main-1
OC-3 Line (using 22-type
OLIUs in FN slots)
all
fn-{1,2,all}
all
fn-1
DS1 port all
{a,b,c,d}-all
{a,b,c,d}-{1}-{1-4,all}
{a,b,c}-{2*}-{1-4,all}
all
b-all
c-1-all
c-2-3
Ports
DS3 port (BBG4/BBG4B,
R3.1 and later)
f,all f
Front Access DS3 port
(BBG19, R3.1 and later)
f-{1,2,all},all f-1
T1 port all
{a,b,c,d}-all
{a,b,c,d}-{1}-{1-2,all}
{a,b,c}-{2*}-{1-2,all}
all
b-all
c-1-all
b-2-2
* The value “2” is only used in shelves where low-speed slots are configured as unprotected.
(Table continues on the following page)
