363-206-305
Commands and Reports
Issue 3 June 2000
11-5
STS-1 Channel (within OC-1) m{1,2}-1 m2-1
STS-1 Channel (within OC-3,
using 28-type OLIUs in Main)
m{1,2}-{1-3,all} m2-3
STS-1 Channel (within OC-12,
using 29-type OLIUs in Main)
m{1,2}-{1-12,all} m2-10
STS-1 Channel (for DS3, R3.1
and later)
ff
STS-3c Channel (within OC-3,
using 28-type OLIUs in Main
and 22-type OLIUs in FN, R3.1
and later)
m{1,2}-1 m2-1
Channels
STS-3c Channel (within OC-
12, using 29-type OLIUs in
Main and 22-type OLIUs in FN,
R4.0 and later)
m{1,2}-{1,4,7,10] m2-4
VT1.5 Channel (within OC-1) m{1,2}-{1,all*}-{1-7,all*}-{1-4,all} m2-1-all
m1-1-4-3
VT1.5 Channel (within OC-3,
using 28-type OLIUs in Main,
R3.1 and later)
m{1,2}-{1-3,all
*
}-{1-7, all*}-{1-4,all} m1-2-all
m2-1-4-3
VT1.5 Channel (within OC-12,
using 29-type OLIUs in Main,
Release 4.0 and later)
m{1,2}-{1-12,all*}-{1-7,all*}-{1-4,all} m1-3-all
m2-7-4-3
Main port (only when 28-type
OLIUs are in Main)
m-{1-3,all} m-2
Main port (only when 29-type
OLIUs are in Main)
m-{1-12,all} m-11
STS-1
Channels for
STS-3c Channels (when 28-
type OLIUs are in Main)
m-1 m-1
Cross -
Connections
STS-3c Channels (when 29-
type OLIUs are in Main, R4.0
and later)
m-{1,4,7,10} m-10
STS-3c Channels (for 22-type
OLIUs in FN, R3.1 and later)
f-1 f-1
STS-1 channel (when FN
equipped with DS3 Circuit
pack)
ff
* If all is chosen as any part of an address, no subsequent address fields should be defined.
(Table continues on the following page)
Table 11-1. DDM-2000 FiberReach Address Table
Object Entity Address Example
