363-206-305
A SONET Overview
A-6 Issue 3 June 2000
SONET Frame Structure A
The following pages provide more detailed information on the function of various
overhead bytes for each SONET layer.
Section Overhead A
Framing (A1, A2)
Provides framing for each STS-1.
STS-1 ID (J0)
Provides the order of appearance in a byte-interleaved STS-
N
frame; for example, STS-1 #1, STS-1 #2......STS-1 #48. In future
applications, this byte will provide a section trace function. For
information on STS-
N
signals, see the "Higher Rate Transport" part
of this section.
Section Bit-Interleaved Parity (BIP-8) (B1)
Provides SECTION performance monitoring and is calculated over
all bits of the previous STS-
N
frame. Defined only for STS-1 #1 of
an STS-
N
signal.
Section Orderwire (E1)
Provides a local orderwire for voice communication channel
between section terminating network elements, such as repeaters.
Defined only for STS-1 #1 of an STS-
N
signal.
Section User Channel (F1)
Set aside for the user's purpose. Defined only for STS-1 #1 of an
STS-
N
signal.
Section Data Communications Channel (D1, D2, D3)
Is a 192 kb/s message-based channel. Used for alarms,
maintenance, control, monitoring, and other communication needs
between section terminating equipment. Defined only for STS-1 #1
of an STS-
N
signal.
