363-206-305
Circuit Pack Descriptions
7-96
Issue 3 June 2000
Channel Units in the Narrowband Shelves
7
Channel Unit Circuit Pack Descriptions
7
Table 7-9 lists the circuit packs that can be housed in the 12-channel unit slots of
the narrowband shelf. All circuit packs within the DDM-2000 FiberReach
narrowband shelf are unprotected. These channel units are the same as those
used in the
SLC
®
-2000 Access System Multi-Services Distant Terminal (MSDT).
Table 7-9 also indicates which circuit packs are available with each
SLC
®
-2000
software release.
Table 7-9. DDM-2000 FiberReach Narrowband Shelf Channel Unit Plug-Ins
Product
Code
Functional Name Available With
SLC
-2000
Release
AUA25B
*
POTS/M SPOTS CU CF (Discontinued Availability) 4.4
AUA27* POTS CF + OHT (Versus feature not available) 4.4
AUA39 POTS/SPOTS CU CS + OHT/CLASS (Discontinued Availability) 4.4
AUA41 4W VF CF (Discontinued Availability) 4.4
AUA41B 4-Wire CF, (FXS/ETO/DX) 4.4
AUA42* E SPOTS CU at COT (Discontinued Availability) 4.4
AUA42B E SPOTS CU at COT 4.4
AUA43B E SPOTS CU CF 4.4
AUA44* 4-Wire VF CS (Includes TDM Signaling) (Discontinued
Availability)
4.4
AUA44B 4W VF CS I (Includes TDM Signaling) 4.4
AUA45B Dual Ringing Repeater (Manual Ring) 4.4
AUA52 OCU Dataport (Discontinued Availability) 4.4
AUA52B OCU Dataport, All-rate 4.4
AUA53 Coin CF
AUA53B Single Coin CF 4.4
AUA54 4W VF Types I and II E&M (Discontinued Availability) 4.4
AUA54B 4W VF Types I and II E+M/PLR 4.4
AUA55 Multiparty CF 4.4
AUA55B Multiparty CF (Discontinued Availability) 4.4
AUA56 DID/DPT (Discontinued Availability) 4.4
AUA56B Dual DID/DPT 4.4
AUA57 FSR CF 4.4
