363-206-305
Administration and Provisioning
Issue 3 June 2000
8-29
Pass-Through Cross-Connection for STS-1
8
Refer to Table 8-10 for a Manual STS-1 Cross Connection (Pass-Through).
Manual STS-3c Cross-Connections
8
The 0x1 OC-3c optical interface provides the ability of transporting STS-3c
services on OC-3c low-speed function units optical interfaces that have been
provisioned for 0X1 applications. The internal system’s application default value
for OC-3 OLIU (22-type) in the function unit is “0x1”. The CIT
ent-crs-sts3c
command is used with a two-way cross-connect type option. Refer to Table 8-11
for FiberReach STS-3c 0 x 1 Cross-Connections.
Table 8-10. DDM-2000 FiberReach Manual STS-1 Cross Connections
(Pass-Through)
From To
Example
CommandsAddress OLIU Address
CP Type
(Notes)
m-{1-3} OC-3
(28-type)
<--> m-{1-3} OC-3 OLIU
(28-type)
ent-crs-sts1:m-1,m-1
cct=twoway,ring={m1,m2}
m-{1-12} OC-12
(29-type)
<--> m-{1-12} OC-12 OLIU
(29-type)
ent-crs-sts1:m-1,m-1
cct=twoway,ring={m1,m2}
Notes
1.Both main units must always be equipped with OC-3 OLIUs or OC-12 OLIUs.
2.
Pass Through Signals
: Address on the left side
must be
identical to the
address on the right side. There is no interchange function for "pass through"
signals.
Table 8-11. DDM-2000 FiberReach STS-3c 0 X 1 Cross-Connections
From To
Example
CommandsAddress OLIU Address
CP Type
(Notes)
m-1 OC-3
(28-type)
<--> f-1 22-type
OLIU
ent-crs-sts1:m-1,f-1
cct=two-way,
cct=two-way
m-1
m-4
m-7
m-10
OC-12
(29-type)
