Lucent Technologies FiberReach DDM-2000 User Manual

363-206-305
Technical Specifications
Issue 3 June 2000
10-47
Performance Monitoring
10
Table 10-23 shows the provisionable range of the thresholds for monitored
parameters and, in brackets, the default thresholds. Thresholding of any
parameter(s) can be disabled.
Table 10-23. Performance Monitoring Parameters Provisionable via the CIT
Parameter Definition Threshold Range [Default] Command
Facility Measure
Current Quarter
Hour Current Day
set-
pmthres-
OC-1/OC-3
*
Section
SE Frame Seconds (SEFS) 1-63[10] 1-4095[30]
sect
OC-1 Line B2 Coding Violations (CV)
B2 Errored Seconds (ES)
B2 Errored Seconds Type A (ESA)
B2 Errored Seconds Type B (ESB)
B2 Severely Errored Seconds (SES)
B2 Unavailable Seconds (UAS)
STS Pointer Justification Counts (PJC)
†
1-4613[461]
1-900[40]
1-900[30]
1-900[30]
1-63[20]
1-63[30]
(1-65535)[60]
1-442848 [44285]
(1-65535)[900]
(1-65535)[90]
(1-65535)[90]
(1-4095)[60]
(1-4095)[90]
1-9999999 [5760]
line
line
line
line
line
line
line
OC-3 Line
*
B2 Coding Violations (CV)
‡
B2 Errored Seconds (ES)
‡
B2 Errored Seconds Type A (ESA)
‡
B2 Errored Seconds Type B (ESB)
‡
B2 Severely Errored Seconds (SES)
‡
B2 Unavailable Seconds (UAS)
‡
1-13841[1384]
1-900[40]
1-900[30]
1-900[30]
1-63[20]
1-63[30]
1-1328736 [132874]
(1-65535)[900]
(1-65535)[90]
(1-65535)[90]
(1-4095)[60]
(1-4095)[90]
line
line
line
line
line
line
OC-12
Section
§
SE Frame Seconds (SEFS) 1-63[10] 1-4095[30]
sect
OC-12 Line
¶
B2 Coding Violations (CV)
B2 Errored Seconds (ES)
B2 Errored Seconds Type A (ESA)
B2 Errored Seconds Type B (ESB)
B2 Severely Errored Seconds (SES)
B2 Unavailable Seconds (UAS)
STS Pointer Justification (PJC)
1-55365 [5537]
1-900 [40]
1-900 [30]
1-900 [30]
1-63 [20]
1-63 [30]
1-65535 [60
]
1-5315040 [531504]
1-65535 [900]
1-65535 [90]
1-65535 [90]
1-4095 [60]
1-4095 [90]
1-9999999 [5760]
line
line
line
line
line
line
line
STS-1 Path B3 Coding Violations (CV)
B3 Errored Seconds (ESA)
B3 Errored Seconds Type A (ESA)
B3 Errored Seconds Type B (ESB)
B3 Severely Errored Seconds (SES)
B3 Unavailable Seconds (UAS)
1-4510[451]
1-900[40]
1-900[30]
1-900[30]
1-63[20]
1-63[30]
1-432960 [43296]
1-65535[900]
1-65535[90]
1-65535[90]
1-4095[60]
1-4095[90]
sts1
sts1
sts1
sts1
sts1
sts1
VT1.5 Path V5 Errored Seconds (ES)
**
V5 Severely Errored Seconds (SES)**
V5 Unavailable Seconds (UAS)**
1-900 [40]
1-63[20]
1-63[30]
1-65535 [900]
1-4095 [60]
1-4095 [90]
vtl
vtl
vtl
