363-206-305

Circuit Pack Descriptions

7-12

Issue 3 June 2000

Figure 7-4. DDM-2000 FiberReach Multiplexer ECC2 User Panel

Critical Alarm

Major Alarm

Minor Alarm

Power Minor Alarm

ACO/LED Test

Power A

Power B

Abnormal

Near-End Activity

Far-End Activity

Craft Interface

Terminal

Connector

PMN

ABN

ACTY

PWR

ACO

TEST

VDC

Bar Code

Label

ECC2
