363-206-305

Circuit Pack Descriptions

7-90

Issue 3 June 2000

Figure 7-34.

Optical System Interfaces (Points S and R)

OLIU

Point S

Transmitter

(Tx)

Transmitter/Connector

Assembly

Station Cable

Fiber

Crossconnect

Fiber

Crossconnect

Outside Plant Cable

Connections

OLIU

(Rx)

Assembly

Station Cable

Receiver

Receiver/Connector

Point R
