Lucent Technologies FiberReach DDM-2000 User Manual

363-206-305
Circuit Pack Descriptions
7-62
Issue 3 June 2000
Transmission - Optical Interface
7
Universal Optical Connectors
7
Circuit packs having a "-U" after their designation indicate that these circuit packs
have a universal optical connector.
The following circuit packs are available with the connector:
■
22D-U OLIU
■
22F/22F-U/22F2-U
■
22G-U/22G2-U/22G3-U/22G4-U*
OLIU
■
26G2-U OLIU
■
28G-U/28G2-U OLIU
■
29G-U/29H-U* OLIU
*Ship with SC buildout and ST shipped loose with each pack except 22G-U.
The only ST-type connector that applies and is shipped for 22G-U is for the
faceplate.
This connector (Figure 7-25) is a two-part connector consisting of a faceplate-
mounted block and an optical buildout. The faceplate block optionally supports an
ST, SC, or FC-type optical buildout.
A 0 dB
SC
-type connector is shipped as standard with OLIU. Optional ST 0 dB
buildouts are shipped loose with each OLIU except for 22G-Us. Optional SC, ST,
or FC-PC 0 dB or attenuated buildouts can be ordered separately. See Chapter
10, "Technical Specifications," for a list of universal buildout attenuators. All OLIUs
will phase to SC buildout mounted and ST shipped loose.
