Lucent Technologies FiberReach DDM-2000 User Manual

363-206-305
Technical Specifications
10-58
Issue 3 June 2000
!
CAUTION:
This information is for a typical application only. Consult 801-525-168, DDM-2000 Floor Plan
Data Sheets, and T82046-30, Power Systems DC Distribution Circuit for Digital Transmission
System, for proper engineering of battery plant and feeders.
DDM-2000 FiberReach WBS with 8 BBF6 (T1EXT)
circuit packs (14 T1EXT, 1x7 protected) and 2 BBG19
circuit packs
— 74 Watts 78 Watts
DDM-2000 FiberReach WBS with 3* BBF8 circuit packs
(6 HDSL, unprotected) and 2 BBG19 circuit packs
— 52 Watts 56 Watts
DDM-2000 FiberReach WBS with 2 22D-U circuit packs — 44 Watts 48 Watts
DDM-2000 FiberReach WBS with 2 BBG4B circuit
packs
— 35 Watts 39 Watts
DDM-2000 FiberReach WBS with 2 BBG19 circuit
packs
— 35 Watts 39 Watts
DDM-2000 FiberReach WBS with 2 22G4-U circuit
packs
— 43 Watts 47 Watts
* Limited to 3 due to power limitations from a single 28-type.
Configuration
Power Dissipation
with 2
26G2-U
with 2
28-Type
with 29G-U
or 29H-U
