363-206-305 Detailed Level Procedure:
DLP-514
Issue 3, June 2000 Page 21 of 22
DDM-2000 F
IBER
R
EACH
W
IDEBAND
S
HELF
Figure 8. Sample Report From rtrv-map-neighbor Command (Release 3.0)
Figure 9. Sample Report From rtrv-map-neighbor Command (Release 3.1 and
Later)
18. After all connections and tests have been made, verify optical fiber cables are
placed correctly in fiber tray/rings and properly routed in bay framework.
Reinstall front cover and tighten three screws.
19. Repeat this procedure for each fiber span to be connected until the end-to-end
system is established.
20. STOP. YOU HAVE COMPLETED THIS PROCEDURE.
*/
Site6NE1/* Network Map for
Site6NE1 FiberReach
39 840F 80 000000 0000 0000 0000 08006alad06e 00
Site7NE1 main-1
39 840F 80 000000 0000 0000 0000 08006a1ad06f 00
Site5NE1 main-2
39 840F 80 000000 0000 0000 0000 00000e3a0372 00
TID Connected Thru Product Type Level 2 IS
NSAP
=================================================================
=================================================================
*/
Site6NE1/* Network Map for
Site6NE1 FiberReach
39 840F 80 000000 0000 0000 0000 08006alad06e 00
Site7NE1 main-1
39 840F 80 000000 0000 0000 0000 08006a1ad06f 00
Site5NE1 main-2 ? N
39 840F 80 000000 0000 0000 0000 00000e3a0372 00
TID Connected Thru Product Type Level 2 IS DCC
NSAP
======================================================================
======================================================================
