363-206-305
Shelf Descriptions and Configurations
Issue 3 June 2000
3-37
Secured-Area Telecommunication
Applications Cabinet (STAC) System
3
The DDM-2000 FiberReach Narrowband and Wideband Multiplexers are available
in the new modular indoor cabinet. The STAC System targets the needs of the
local access market with a flexible and affordable configuration.
Each cabinet is assembled and can be completely wired and system tested at the
factory to assure the highest standard of quality and quick trouble free installation.
There are two modules available:
■
FRC-2000 module (26” W x 15” D x 12” H)
■
Pedestal battery module (26” W x 15” D x 24” H).
Features of the 12” module include:
■
Wall mountable
■
Floor mountable with spacer
■
Spacer that allows the user to stack modules on top of each other
■
Holds a combination of two FiberReach shelves
— 1 wideband shelf and 1 narrowband shelf
— 2 narrowband shelves
■
Holds up to two rectifiers
— Lucent Technologies RSO 400 Series
— 400 watts each
■
Fiber administration shelf
■
Tilts down for easy access to back of equipment
■
Allows access to rear of module to facilitate cable administration.
Features of the pedestal battery module include:
■
Floor mountable
■
Front door removable and provisioned for padlock
■
Spacer that allows electronic module to be stacked on top
■
Holds up to 2 string of batteries
— Lucent Technologies’ HR Series Battery
■
Provides up to 8 hours of battery backup
■
Includes low voltage disconnect and fusing unit.
