Circuit Pack Descriptions
7-44
Issue 3 June 2000
Table 7-6. T1EXT Line Code Settings
T1EXT Line Code Settings (Notes)
Line Code
Format
DIP Switch Settings
S1-4
(Port 1)
S1-5
(Port 2)
S1-6
(Port 3)
S1-7
(Port 4)
B8ZS OFF OFF OFF OFF
AMI ON ON ON ON
Notes:
1. Switch section 8 (S1-8) is unused and must be off.
2. Line code is software overrideable.
