Lucent Technologies FiberReach DDM-2000 User Manual

363-206-305
Circuit Pack Descriptions
Issue 3 June 2000
7-59
■
Special Loopback Code Detection: A1LB, A2LB, A3LB, A4LB, or A5LB
■
Errored Second Threshold: NONE, 17, or 170 per 24 hours
■
Loopback Time-out: NONE, 20, 60, 120 minutes
■
Alarm Notification: ENABLE or DISABLE
■
Allocation of DS0 time slots on HDSL loop: ALTERNATE or CONTIGUOUS
■
Margin Alarm Threshold: 0-15 dB, 1 dB increments
■
DS0 blocking: individually (T1, FT1)
■
Fast Loss of Sync Word (LOSW): ENABLE or DISABLE.
Performance Monitoring
7
From any unit in a system, HDSL performance data may be accessed for each
HDSL span in the circuit, including up to two HDSL doublers (three total HDSL
spans). Access to all PM data is through the faceplate RS-232 port only. Any unit
provides access to the following:
■
HDSL Span Current Status:
■
Alarms
■
Loopbacks
■
Margins
■
HDSL Pulse Attenuation
■
HDSL clock offset (PPM)
■
24-hour HDSL Errored Seconds
■
24-hour HDSL Unavailable Seconds.
■
HDSL Span History:
■
15-min, 24-hour, 7-day HDSL Errored Seconds
■
15-min, 24-hour, 7-day HDSL Unavailable Seconds.
■
HDSL Alarm History
■
LOSW, HDSL1 - Loss of Sync on Loop 1
■
LOSW, HDSL2 - Loss of Sync on Loop 2
■
ES, HDSL1 - Exceeded ES Threshold on Loop 1
■
ES, HDSL2 - Exceeded ES Threshold on Loop 2
■
Margin, HDSL1 - Exceeded Threshold on Loop 1
■
Margin, HDSL2 - Exceeded Threshold on Loop 2.
