363-206-305
Circuit Pack Descriptions
7-68
Issue 3 June 2000
7
Figure 7-27. 22F-U OLIU Circuit Pack
OLIU
x
x
x
x
x
Universal
Optical
Connectors
AT&T
AT&T
22F-U
FAULT
ACTIVE
S1:1
IN
OUT
tpa 851683/01
