363-206-305
Technical Specifications
10-14
Issue 3 June 2000
Table 10-4 lists the 22D-U OLIU specifications.
Table 10-4. 22D-U OLIU Specifications
System Information: 22D-U
Terminal Equipment Identification
Optical Line Rate (Mb/s)
Optical Line Coding
Optical Wavelength
Performance
22D-U OLIU
155.520 Mb/s
Scrambled NRZ
1310 nm
Not applicable
Transmitter Information:
Optical Device Temperature Controller
FDA Classification
Optical Source
Faceplate Optical Connector
No TEC
Class I
LED
Lucent ST
UOC buildout assembly *
Multimode
Receiver Information:
Optical Device Temperature Controller
Optical Detector
Faceplate Optical Connector
None
InGaAsP PIN
UOC buildout assembly *
Multimode
*
The universal optical connector (UOC) buildout assembly consists of a faceplate-mounted
block assembly and either 0 dB, 5 dB, 10 dB, or 15 dB buildout in either ST, SC, or FC-type
connectors.
