363-206-305
Technical Specifications
Issue 3 June 2000
10-19
Table 10-6 lists the 22F-type and 22G-type OLIU specifications.
Table 10-6. 22F-Type and 22G-Type OLIU Specifications
Notes:
System Information:
22F-Type 22G-U/22G2-U 22G3-U/22G4-U
Terminal Equipment Identification
Optical Line Rate (Mb/s)
Optical Line Coding
Optical Wavelength
Performance
22F/22F-U/22F2-U OLIU
155.520 Mb/s
Scrambled NRZ
1310 nm
SONET IR-1 MLM
(Intermediate Reach)
22G-U/22G2-U OLIU
155.520 Mb/s
Scrambled NRZ
1310 nm
Not applicable
22G3-U OLIU
155.520 Mb/s
Scrambled NRZ
1310 nm
SONET LR-
(Long Reach)
Transmitter Information:
Optical Device Temperature
Controller
FDA Classification
Optical Source
Faceplate Optical Connector
No TEC
Class I
InGaAsP Laser,
MLM Structure
*
Lucent C3000-A-2 (22F)
UOC buildout assembly †
(22F-U/22F2-U)
Single Mode
No TEC
Class I
InGaAsP Laser,
MLM Structure
*
UOC buildout
assembly †
Single Mode
No TEC
Class I
InGaAsP Laser,
MLM Structure
*
UOC buildout
assembly †
Single Mode
Receiver Information:
Optical Device Temperature
Controller
Optical Detector
Faceplate Optical Connector
None
InGaAsP PIN
Lucent C2000-A-2 (22F)
UOC buildout assembly †
(22F-U/22F2-U)
Multimode
None
InGaAsP PIN (22G-U)
InGaAs PIN (22G2-U)
UOC buildout
assembly †
Multimode
None
InGaAs PIN
UOC buildout
assembly †
Multimode
*
A tighter specification DFB laser (part #1243TAFA) may be supplied instead of the MLM laser. The DFB
laser meets all the requirements of the MLM laser and DFB requirements in GR-253-CORE, Issue 2,
December 1995.
† The universal optical connector (UOC) buildout assembly consists of a faceplate-mounted block
assembly and either 0 dB, 5 dB, 10 dB, or 15 dB buildout in either ST, SC, or FC-type connectors. ST
universal buildout does not apply to 22G-U.
