3. SPECIFICATIONS
3.1. MODEL NUMBERING
Code number: SC [0] – [1] [2] – [3] [4]
[0] MODEL
100 : Basic model
110 : Basic model with MV output backup
200 : Modbus extension model
210 : Modbus extension model with MV output backup
[1] DISCRETE OUTPUT
1 : Relay contact
2 : Photo MOSFET relay
[2] MODBUS
0 : None (SC100/110)
1 : Modbus-RTU (SC200/210)
2 : Modbus/TCP (SC200/210)
[3] POWER INPUT
M2 : 100 – 240 V AC
R : 24 V DC
[4] OPTIONS
Housing Depth
model
code
SC100 SC110 SC200 SC210
blank 250 mm --- 250 mm ---
/3 300 mm 300 mm 300 mm 300 mm
/4 400 mm 400 mm 400 mm 400 mm
/6 600 mm 600 mm --- ---
Backup Module Power Supply
SC110/210
blank : Single supply
/M2 : 100 – 240 V AC (dual supply)
/R : 24 V DC (dual supply)
Control/Backup modules are powered from common terminals with ‘single’
supply type; powered from independent terminals with ‘dual’ supply type.
Language
blank : Japanese
/E : English
Language (Japanese or English) can be chosen by front panel setting.
Congurator Interface
blank : Infrared
/1 : Stereo jack
If external noise interference is a concern, stereo jack type is
recommended.
Terminal Block
blank : One block terminal
/T : Separable terminal
Other Options
blank : none
/Q : Option other than the above (specify the specication)

M-system SC100 Specifications

General

Brand	M-system
Model	SC100
Category	Controller
Language	English
