SC100/200 Series Users Manual EM-6337-B Rev.15
3.6. SUPPLY OUTPUT
Output voltage 24 V DC ±10 % (with no load)
18 V DC min. at 20 mA
Current rating ≤ 22 mA DC
Shortcircuit protection Current limited to approx. 30 mA
3.7. INPUT SPECIFICATIONS
■ Pv1, Pv2
DC CURRENT
Current input 4 – 20 mA DC with input resistance 250 Ω (REM4)
DC VOLTAGE
Voltage input -10 – +10 V DC
-1 – +1 V DC
0 – 10 V DC
1 – 5 V DC
0 – 1 V DC
Input resistance ≥ 1 MΩ
THERMOCOUPLE
Thermocouple input K, E, J, T, B, R, S, C, N, U, L, P, PR
Input resistance ≥ 30 kΩ
Burnout sensing ≤ 0.3 µA
Burnout indication 115 % of the measuring range (upscale)
Temperature range
T/C
USABLE
RANGE (°C)
CONFORMANCE
RANGE (°C)
K (CA) -272 to +1472 -150 to +1370
E (CRC) -272 to +1100 -170 to +1000
J (IC) -260 to +1300 -180 to +1200
T (CC) -272 to +500 -170 to +400
B (RH) 24 to 1920 1000 to 1760
R -100 to +1860 380 to 1760
S -100 to +1860 400 to 1760
C (WRe 5-26) -52 to +2416 100 to 2315
N -272 to +1400 -130 to +1300
U -252 to +700 -200 to +600
L -252 to +1000 -200 to +900
P (Platinel II) -52 to +1496 0 to 1395
(PR) -52 to +1860 300 to 1760
Overrange input (out of the usable range) is handled as burnout.
RTD
RTD input Pt100 (JIS ’97, IEC), Pt100 (JIS ’89), JPt100 (JIS ’89), Pt50Ω (JIS ’81), Ni100
Max. lead wire resistance 100 Ω per wire
Burnout indication 115 % of the measuring range (upscale)
Sensing current ≤ 1 mA
Temperature range
RTD
USABLE
RANGE (°C)
CONFORMANCE
RANGE (°C)
Pt 100 ( JIS ’97, IEC ) -240 to +900 -200 to +850
Pt 100 (JIS ’89) -240 to +900 -200 to +660
JPt 100 (JIS ’89) -236 to +560 -200 to +510
Pt 50
Ω (JIS ’81)
-236 to +700 -200 to +649
Ni 100 -100 to +252 -80 to +250
Overrange input (out of the usable range) is handled as burnout.
POTENTIOMETER
Potentiometer input Total resistance 100 Ω to 10 kΩ
Minimum span 50 % of total resistance
Excitation ≤ 0.6 V DC
