16
SC100/200 Series Users Manual EM-6337-B Rev.15
3.8. OUTPUT SPECIFICATIONS
■ Mv1, Mv2, Mv2B
Current output 4 – 20 mA DC
Load resistance ≤ 600 Ω
■ Ao1, Ao2
Voltage output 1 – 5 V DC
Load resistance ≥ 10 kΩ
■ Do1, Do2, Do3, Do4, Do5, RUN CONTACT
RELAY OUTPUT
Relay contact Do1, Do2, Do3, Do4, Do5, RUN contact (Do6)
Relay rating
250 V AC @1 A (cos φ = 1)
30 V DC @1 A (resistive load)
Maximum switching voltage 250 V AC or 30 V DC
Maximum switching power 250 VA or 60 W
Minimum load 5 V DC at 10 mA
Mechanical life 2 × 10
7
cycles
PHOTO MOSFET RELAY
Photo MOSFET relay Do1, Do2, Do3, Do4, Do5
Rating 200 V AC/DC @0.5 A (resistive load)
ON resistance 2.1 Ω
Maximum frequency 4 Hz at 24 V, 10 mA
ON delay time ≤ 5.0 msec.
OFF delay time ≤ 3.0 msec.
3.9. INSTALLATION
Power input AC power Operational voltage range 85 – 264 V AC; 50/60 Hz
Control module:
≤ 25 VA at 100 V AC
≤ 40 VA at 240 V AC
Backup module (SC110/210):
≤ 10 VA at 100 V AC
≤ 15 VA at 240 V AC
DC power Operational voltage range 24 V DC ±10 %
Ripple 10 %p-p max.
Control module: ≤ 650 mA
Backup module (SC110/210): ≤ 150 mA
Operational temperature range -5 to +55°C (23 to 131°F)
Operating humidity 5 to 90 %RH (non-condensing)
Mounting Panel ush mounting (high-density mounting available)
Panel cutout 68 x 138 mm
Panel thickness 2.3 to 20 mm (0.1 to 0.78”)
Weight Approx. 1.8 kg (3.97 lb) for 250 mm depth type
Approx. 2.0 kg (4.41 lb) for 300 mm depth type
Approx. 2.5 kg (5.51 lb) for 400 mm depth type
Approx. 3.0 kg (6.61 lb) for 600 mm depth type
