SC100/200 Series Users Manual EM-6337-B Rev.15
3.2. RELATED PRODUCTS
The following products are required for the setting up of the device via PC (not included in the package.)
• PC Congurator Software (model: SCCFG Ver. 1.50 or later) Downloadable at M-System’s web site.
• Loop Conguration Builder Software (model: SFEW3E Ver. 1.40 or later). Downloadable at M-System’s web site.
• Infrared Communication Adaptor (model: COP-IRDA)
• PC Congurator Cable (model: COP-US)
3.3. GENERAL SPECIFICATIONS
Construction Panel ush mounting
Degree of protection IP55; applicable to the front panel for single unit mounted according to the
specied panel cutout
Connection Terminal screws: M3.5 screw terminals (torque 1.0 N·m)
Terminal xing screws: M4 screw terminals (torque 1.2 N·m)
Screw terminal Terminal screws: Nickel-plated steel (standard) or stainless
Terminal xing screws: Chrome-plated steel
Backup module power supply terminal
(option /M2, /R)
SC110/210
Euro terminal block (wire dia. 2.4 max., 0.5 – 2.5 mm
2
, stripped length: 10
mm)
Housing material Flame-resistant resin (gray), steel
Isolation SC100/110 Pv1 to Pv2 to supply output to Ai1 or Ai2 or Ai3 or Ai4 to Di1 or Di2 or Di3 or
Di4 or Di5 or Pi1 or Pi2 or Pi3 or Pi4 or Pi5 to Di6 or Pi6 to Mv1 to Mv2 (or
Mv2B)
*1
to Ao1 or Ao2 to Do1 to Do2 to Do3 to Do4 to Do5 to Do6 to power
(to backup module power)
*1
to FG *1. SC110
SC200/210 Pv1 to Pv2 to supply output to Ai1 or Ai2 or Ai3 or Ai4 to Di1 or Di2 or Di3 or
Di4 or Di5 or Pi1 or Pi2 or Pi3 or Pi4 or Pi5 to Di6 or Pi6 to Mv1 to Mv2 (or
Mv2B)
*2
to Ao1 or Ao2 to Do1 to Do2 to Do3 to Do4 to Do5 to Do6 to NestBus
to Modbus-RTU to Modbus/TCP to power (to backup module power)
*2
to FG
*2. SC210
PID control Single loop, cascade, advanced
Proportional band (P) 1 to 1000 %
Integral time (I) 0.01 to 100 minutes
Derivative time (D) 0.01 to 10 minutes
Auto-tuning Limit cycle method
Alarm PV high & low, deviation, rate of change
Computation 48 functions blocks available for arithmetic operations, time functions, signal
selection, limit alarm and other functions
Sequence operation Logic sequence and step sequence (max. 1068 commands)
Computation cycle 50 msec. to 3 sec. (control cycle selectable among 1, 2, 4, 8, 16, 32 and 64
times of the computation cycle)
MV output range -15 to +115 %
Parameter setting With touch panel or PC
(Loop Conguration Builder Software model: SFEW3E)
Self diagnostics CPU monitoring with a watchdog timer
RUN contact OFF in error detected by diagnostic (including NestBus for SC200/210)
Infrared communication Transmission distance max. 0.2 meter (for use with the COP-IRDA)
Short trend
SC200/210
Storing interval: 1, 2, 5, 10, 20, 30 sec., 1, 2, 5, 10, 30, 60 min.
Capacity: 400 points (display 200 points)
