108
SC100/200 Series Users Manual EM-6337-B Rev.15
Appx 2. FUNCTION BLOCK PARAMETERS DEFAULT SETTING
(Initial values provided when ITEM 10 is set)
GROUP 01: FIELD TERMINAL
GROUP ITEM ABBR DATA PARAMETER
01
11 GR 2 Primary loop Group No. (valid after reset)
12 M1 0 Primary MV operational range (0: ±115%, 1: -15 – +115%)
13 M2 0 Secondary MV operational range (0: ±115%, 1: -15 – +115%)
15 1F 0000 FN1 connection terminal for indication (GG: Group No., NN: terminal No.)
16 1H 10000 FN1 upper range (in engineering unit)
17 1L 0 FN1 lower range (in engineering unit)
18 1D 2 FN1 decimal point position (from rightmost digit)
19 2F 0000 FN2 connection terminal for indication (GG: Group No., NN: terminal No.)
20 2H 10000 FN2 upper range (in engineering unit)
21 2L 0 FN2 lower range (in engineering unit)
22 2D 2 FN2 decimal point position (from rightmost digit)
23 3F 0000 FN3 connection terminal for indication (GG: Group No., NN: terminal No.)
24 3H 10000 FN3 upper range (in engineering unit)
25 3L 0 FN3 lower range (in engineering unit)
26 3D 2 FN3 decimal point position (from rightmost digit)
27 4F 0000 FN4 connection terminal for indication (GG: Group No., NN: terminal No.)
28 4H 10000 FN4 upper range (in engineering unit)
29 4L 0 FN4 lower range (in engineering unit)
30 4D 2 FN4 decimal point position (from rightmost digit)
31 T1 Tag No. FN1 tag name (max. 10 characters)
32 T2 Tag No. FN2 tag name (max. 10 characters)
33 T3 Tag No. FN3 tag name (max. 10 characters)
34 T4 Tag No. FN4 tag name (max. 10 characters)
35 U1 Unit FN1 engineering unit (max. 8 characters)
36 U2 Unit FN2 engineering unit (max. 8 characters)
37 U3 Unit FN3 engineering unit (max. 8 characters)
38 U4 Unit FN4 engineering unit (max. 8 characters)
43 L1 AL1 AL1 comment (max. 4 characters)
44 L2 AL2 AL2 comment (max. 4 characters)
45 L3 AL3 AL3 comment (max. 4 characters)
46 L4 AL4 AL4 comment (max. 4 characters)
To Next Page
