109
SC100/200 Series Users Manual EM-6337-B Rev.15
GROUP 04: EXTENSION FIELD TERMINAL 1
GROUP ITEM ABBR DATA PARAMETER
04
25 M1# 0099
Mv 1 connection terminal (error if not connected)
(GG: Group No., NN: terminal No.)
26 M2# 0099
Mv 2 connection terminal (error if not connected)
(GG: Group No., NN: terminal No.)
27 A1# 0099
Ao 1 connection terminal (error if not connected)
(GG: Group No., NN: terminal No.)
28 A2# 0099
Ao 2 connection terminal (error if not connected)
(GG: Group No., NN: terminal No.)
30 PH1 115.00 Pv 1 high alarm setpoint (for error judgment)
31 PL1 -15.00 Pv 1 low alarm setpoint (for error judgment)
32 PH2 115.00 Pv 2 high alarm setpoint (for error judgment)
33 PL2 -15.00 Pv 2 low alarm setpoint (for error judgment)
34 ML1 115.00 Mv 1 deviation alarm setpoint (for error judgment)
35 ML2 115.00 Mv 2 deviation alarm setpoint (for error judgment)
36 TP1 3 Pv 1 input type
37 HT1 1000.0 Pv 1 upper range temperature
38 LT 1 0.0 Pv 1 lower range temperature
39 CJ1 1 Pv 1 cold junction compensation (0: without, 1: with)
40 TP2 3 Pv 2 input type
41 HT2 1000.0 Pv 2 upper range temperature
42 LT 2 0.0 Pv 2 lower range temperature
43 CJ2 1 Pv 2 cold junction compensation (0: without, 1: with)
50 PZ1 0.00 Pv 1 zero adjustment (zero bias)
51 PS1 1.0000 Pv 1 span adjustment (gain)
52 PZ2 0.00 Pv 2 zero adjustment (zero bias)
53 PS2 1.0000 Pv 2 span adjustment (gain)
54 MZ1 0.00 Mv 1 zero adjustment (zero bias)
55 MS1 1.0000 Mv 1 span adjustment (gain)
56 MZ2 0.00 Mv 2 zero adjustment (zero bias)
57 MS2 1.0000 Mv 2 span adjustment (gain)
58 IZ1 0.00 Ai 1 zero adjustment (zero bias)
59 IS1 1.0000 Ai 1 span adjustment (gain)
60 IZ2 0.00 Ai 2 zero adjustment (zero bias)
61 IS2 1.0000 Ai 2 span adjustment (gain)
62 IZ3 0.00 Ai 3 zero adjustment (zero bias)
63 IS3 1.0000 Ai 3 span adjustment (gain)
64 IZ4 0.00 Ai 4 zero adjustment (zero bias)
65 IS4 1.0000 Ai 4 span adjustment (gain)
66 CZ1 0.00 Mv 1 check input zero adjustment (zero bias)
67 CS1 1.0000 Mv 1 check input span adjustment (gain)
68 CZ2 0.00 Mv 2 check input zero adjustment (zero bias)
69 CS2 1.0000 Mv 2 check input span adjustment (gain)
70 OZ1 0.00 Ao 1 zero adjustment (zero bias)
71 OS1 1.0000 Ao 1 span adjustment (gain)
72 OZ2 0.00 Ao 2 zero adjustment (zero bias)
73 OS2 1.0000 Ao 2 span adjustment (gain)
81 BSW 0 Automatic switching (0: disable, 1: enable)
82 BMD 0 Backup control mode (0: track back, 1: preset value)
83 BVL 0 Output rate-of-change limit (0: no limit applied)
84 BFV 0 Preset value (applicable with ITEM 82 DATA 1)
85 BBL 0 Backup recovery mode (0: auto tracking, 1: manual tracking)
86 BGR 3 Backup GROUP
ITEM 81 through 86 are available for the SC110/210 only.
