110
SC100/200 Series Users Manual EM-6337-B Rev.15
GROUP 05: EXTENSION FIELD TERMINAL 2
GROUP ITEM ABBR DATA PARAMETER
05
31 PD 00000
Di/Pi selection (0 = Di, 1 = Pi)
(10
0
: Di1, 10
1
: Di2, 10
2
: Di3, 10
3
: Di4, 10
4
: Di5)
32 KR 1 Pi moving average sample number for momentary value conversion
33 D1 0
Qi 1 power-law scaling
(10’s power 1: x 10, 0: x 1, -1: x 0.1, -2: x 0.01, -3: x 0.001)
34 S1 1.0000 Qi 1 scaling factor
35 K1 1000.00
QA 1 momentary value conversion factor
(number of pulses per second at 100% momentary value output)
36 D2 0
Qi 2 power-law scaling
(10’s power 1: x 10, 0: x 1, -1: x 0.1, -2: x 0.01, -3: x 0.001)
37 S2 1.0000 Qi 2 scaling factor
38 K2 1000.00
QA 2 momentary value conversion factor
(number of pulses per second at 100% momentary value output)
39 D3 0
Qi 3 power-law scaling
(10’s power 1: x 10, 0: x 1, -1: x 0.1, -2: x 0.01, -3: x 0.001)
40 S3 1.0000 Qi 3 scaling factor
41 K3 1000.00
QA 3 momentary value conversion factor
(number of pulses per second at 100% momentary value output)
42 D4 0
Qi 4 power-law scaling
(10’s power 1: x 10, 0: x 1, -1: x 0.1, -2: x 0.01, -3: x 0.001)
43 S4 1.0000 Qi 4 scaling factor
44 K4 1000.00
QA 4 momentary value conversion factor
(number of pulses per second at 100% momentary value output)
45 D5 0
Qi 5 power-law scaling
(10’s power 1: x 10, 0: x 1, -1: x 0.1, -2: x 0.01, -3: x 0.001)
46 S5 1.0000 Qi 5 scaling factor
47 K5 1000.00
QA 5 momentary value conversion factor
(number of pulses per second at 100% momentary value output)
48 D6 0
Qi 6 power-law scaling
(10’s power 1: x 10, 0: x 1, -1: x 0.1, -2: x 0.01, -3: x 0.001)
49 S6 1.0000 Qi 6 scaling factor
50 K6 1000.00
QA 6 momentary value conversion factor
(number of pulses per second at 100% momentary value output)
51 DM 0
Error detected by diagnostic
(0: Normal conditions, 1: All discrete outputs OFF with RUN contact OFF
52 PD6 1 PD6: Select Discrete / Pulse input 0 = Di, 1 = Pi
