SC100/200 Series Users Manual EM-6337-B Rev.15
GROUP 02, 03: PID CONTROLLER
GROUP
ITEM ABBR
Basic PID
DATA
Adv. PID
DATA
MV Man.
DATA
Ratio Setter
DATA
Indicator
DATA
PARAMETER
02, 03
15 P# 0000 0000 ---- 0000 0000 PV connection terminal
17 PT ---- .0 ---- ---- ---- PV rst order lag time constant
19 PH 115.00 115.00 ---- 115.00 115.00 PV high alarm setpoint
20 PL -15.00 -15.00 ---- -15.00 -15.00 PV low alarm setpoint
21 HS 1.00 1.00 ---- 1.00 1.00 Hysteresis (deadband)
24 C# 0000 0000 ---- 0000 ---- CAS connection terminal
26 RT ---- 1.000 ---- ---- ---- Ratio setting (signal % ratio)
27 SP .00 .00 ---- 1.000 ---- Local SP %
29 SM 0 0 ---- 0 ---- Setting method (0: local)
30 03 0 0 ---- 0 ---- Cas/Loc SW (0: local)
32 SR ---- .00 ---- ---- ---- SP rate-of-change limit (0: without)
34 DL 115.00 115.00 ---- ---- ---- Deviation alarm setpoint
37 06 ---- 0 ---- ---- ---- Input compensation SW (0: without)
38 IM ---- 0 ---- ---- ----
Input compensation method
(0: without)
39 I# ---- 0000 ---- ---- ---- Input compensation connection terminal
40 DR 0 0 ---- .00 ----
Control action (0: direct [MV increases with PV
increase])
41 DM 0 0 ---- .00 ---- Derivative method (0: PV derivative)
42 PB 100 100 ---- ---- ---- Proportional band
43 TI .00 .00 ---- ---- ---- Integral time (0: no integral action)
44 TD .00 .00 ---- ---- ----
Derivative time
(0: no derivative action)
45 CP 1 1 ---- ---- ----
Control cycle
(multiple of basic control cycle)
47 07 ---- 0 ---- ---- ---- Output compensation SW (0: without)
48 OM ---- 0 ---- ---- ----
Output compensation method
(0: without)
49 0# ---- 0000 ---- ---- ---- Output compensation connection terminal
50 MH 115.00 115.00 ---- ---- ---- Output high limit
51 ML -115.00 -115.00 ---- ---- ---- Output low limit
53 MI .00 .00 ---- ---- ---- Preset value
54 MR ---- .00 ---- ---- ---- Output rate-of-change limit (0: without)
56 M# ---- 0000 ---- ---- ---- External feedback connection terminal
59 11 0 0 ---- 0 ---- Auto/Man SW (0: manual)
60 MV .00 .00 .00 .00 ---- Supervisory indication / manipulated MV %
64 RS 50.00 50.00 ---- ---- ---- Manual reset
66 MS 0 0 ---- ---- ----
Smooth tracking output with local SP change
(0: without)
80 TG Tag No. Tag No. Tag No. Tag No. Tag No. Tag name
81 TC
Ta g
Comment
Ta g
Comment
Ta g
Comment
Ta g
Comment
Ta g
Comment
Tag comment
82 MH 10000 10000 ---- 10000 10000 Upper range
83 ML 0 0 ---- 0 0 Lower range
84 DP 2 2 ---- 2 2
Decimal point position
(from rightmost digit)
85 TU Unit Unit ---- Unit Unit Engineering unit
86 MD 0 0 0 0 ---- MV reverse indication (0: direct)
