41
SC100/200 Series Users Manual EM-6337-B Rev.15
MAIN PARAMETER DEFAULT SETTING
GROUP ITEM DATA PARAMETER
01
10 11 Field Terminal
43 AL1 AL1 message
44 AL2 AL2 message
45 AL3 AL3 message
46 AL4 AL4 message
02
10 21 Basic PID
15 0421 G04 (SC) Pv 1 is assigned to Basic PID PV connection terminal.
19 115 PV high alarm setpoint
20 -15 PV low alarm setpoint
24 0423 G04 (SC) Ai 1 is assigned to Basic PID CAS connection terminal.
29 0 Setting method (0: LOCAL)
40 1 Control direction (reverse: MV decreases with PV increasing)
82 10000 Upper range (in engineering unit)
83 0 Lower range (in engineering unit)
84 2 Decimal point position (from rightmost digit)
86 0 MV reverse indication (direct)
03
10 21 Basic PID
15 0422 G04 (SC) Pv 2 is assigned to Basic PID PV connection terminal.
19 115 PV high alarm setpoint
20 -15 PV low alarm setpoint
24 0424 G04 (SC) Ai 2 is assigned to Basic PID CAS connection terminal.
29 0 Setting method (0: LOCAL)
40 1 Control direction (reverse: MV decreases with PV increasing)
82 10000 Upper range (in engineering unit)
83 0 Lower range (in engineering unit)
84 2 Decimal point position (from rightmost digit)
86 0 MV reverse indication (direct)
04
10 12 Extension Field Terminal 1
25 0225 G02 (Basic PID) MV output is assigned to Mv 1 connection terminal of SC Field Terminal.
26 0325 G03 (Basic PID) MV output is assigned to Mv 2 connection terminal of SC Field Terminal.
81
10 95 Sequential Control
11 13 : 0000 Step command
12 01 : 0202 G02 (Basic PID) PV low alarm is assigned to G01 (SC) AL1 lamp input terminal.
13 07 : 0101
14 01 : 0201 G02 (Basic PID) PV high alarm is assigned to G01 (SC) AL2 lamp input terminal.
15 07 : 0102
12 01 : 0302 G03 (Basic PID) PV low alarm is assigned to G01 (SC) AL3 lamp input terminal.
13 07 : 0103
14 01 : 0301 G03 (Basic PID) PV high alarm is assigned to G01 (SC) AL4 lamp input terminal.
15 07 : 0104
16 00 : 0000 End
Note: Refer to SC100/SC200 Function Block List.
To Next Page
