4.2 Symbol Definitions
These symbols are used to provide at-a-glance information on critical windrower performance parameters.
Ensure that you are familiar with the meaning of these symbols before operating the windrower.
4.2.1 Windrower Operating Symbols
These are the symbols used on the console for windrower operation.
1019378
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
R
S
T
U
V
W
X
Y
Figure 4.1: Windrower Operating Symbols
A - Signal Lights B - Hazard Lights C - Forward
D - Neutral E - Reverse F - Road Lights
G - High Beams H - Cab-forward Field Lights J - Blower Speed (Manual Mode)
K - Air Conditioning L - Windshield Wiper M - Wiper Fluid
N - Float Menu P - Windrower Settings Q - Header Settings
R - Header Engage S - Header Disengage T - Header Reverse
U - Slow V - Fast W - Engine Throttle
X - One-Touch-Return Y - Electrical Power / Accessories
