3.9 Rear View Mirrors
Mirrors provide a view behind the windrower whether the windrower is in cab- or engine-forward driving mode.
Figure 3.34: Mirrors
Two power adjustable mirrors (A) provide a rear view when the
windrower is in cab-forward mode.
Two manually adjustable mirrors (B) provide a rear view in the
engine-forward mode.
Mirror assemblies are designed to fold back if accidentally
struck.
Figure 3.35: Mirror Adjustment Knob
The cab is equipped with power adjustable exterior mirrors for
cab-forward mode, which can be adjusted using knob (A)
located next to the radio inside the cab.
